MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard

MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard
  • Stock: In Stock
  • Brand: MSI
  • Model: B860M GAMING PLUS WIFI6E
  • SKU: B860M GAMING PLUS WIFI6E
Based on 0 reviews. - Write a review
৳27,500
EMI starts at ৳949/month. View all 26 banks EMI plans >
Key Features:
  • Supports Intel Core Ultra Processors (Series 2), LGA 1851
  • Intel B860 chipset, Micro-ATX form factor
  • 4x DDR5 slots, up to 256GB, DDR5 8800+ MT/s (OC)
  • 3x M.2 (1x PCIe 5.0 x4) + 4x SATA 6G
  • PCIe 5.0 x16 slot
  • Intel Killer E5000 5Gbps LAN, Wi-Fi 6E & Blu
Add to Cart
Buy Now Ask Question
Add to Wish List Compare this Product
Product Details

MSI B860M GAMING PLUS WIFI6E LGA1851 Micro ATX Motherboard

The MSI B860M GAMING PLUS WIFI6E is a Micro-ATX motherboard for Intel Core Ultra (Series 2) processors. It combines the Intel B860 chipset with four DDR5 slots, a PCIe 5.0 x16 slot, a PCIe 5.0 M.2 slot, Intel Killer E5000 5Gbps LAN and Wi-Fi 6E in a compact board for gaming builds.

Key Features

  • Supports Intel Core Ultra Processors (Series 2), LGA 1851
  • Intel B860 chipset, Micro-ATX form factor
  • 4x DDR5 slots, up to 256GB, DDR5 8800+ MT/s (OC)
  • 3x M.2 (1x PCIe 5.0 x4) + 4x SATA 6G
  • PCIe 5.0 x16 slot
  • Intel Killer E5000 5Gbps LAN, Wi-Fi 6E & Bluetooth 5.3

Availability: Upcoming at UCC. Contact us for pre-order and launch pricing.

Specification
Motherboard Specification
Chipset INTEL B860
Socket LGA 1851
Form Factor Micro-ATX | 243.84mmx243.84mm
Audio Realtek ALC897 Codec | 7.1-Channel High Definition Audio
Memory Specification
Memory Capacity 4x DDR5 UDIMM, Maximum Memory Capacity 256GB | Memory Support DDR5 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s | Supports Intel POR Speed and JEDEC Speed | Supports Memory Overclocking and Intel XMP 3.0 | Supports Dual-Controller Dual-Channel mode | Supports Non-ECC, Un-buffered memory | Supports CUDIMM
Network & Wireless
Wi-Fi Wi-Fi 6E Solution | The Wireless module is pre-installed in the M.2 (Key-E) slot | Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps | Supports 802.11 a/ b/ g/ n/ ac/ ax
LAN Intel Killer™ E5000 5Gbps LAN
Bluetooth Supports Bluetooth 5.3, FIPS, FISMA
Supports
Supported CPU Supports Intel® Core™ Ultra Processors (Series 2)
Connectors
USB 2x USB 2.0 (Rear) | 4x USB 2.0 (Front) | 2x USB 5Gbps Type A (Rear) | 1x USB 5Gbps Type C (Rear) | 4x USB 5Gbps Type A (Front) | 1x USB 10Gbps Type A (Rear) | 1x USB 10Gbps Type C (Front)
Display Port 1x DisplayPort | Support DisplayPort 1.4, maximum resolution of 4K 60Hz
HDMI 1x HDMI™ | Support HDMI™ 2.1, maximum resolution of 4K 60Hz
Ports & Slots
PCI-E 4x PCI-E x16 slot | PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) | PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) | PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) | PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
Storage 3x M.2 | M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices | M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices | M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280 devices | 4x SATA 6G
Internal I/O Ports 1x Thunderbolt5 card connector(JTBT5, support RTD3) | 1x Power Connector(ATX_PWR) | 2x Power Connector(CPU_PWR) | 1x Power Connector(PCIE_PWR 8pin) | 1x CPU Fan | 1x Combo Fan (Pump_Sys Fan) | 3x System Fan | 1x EZ Conn-header (JAF_1) | 2x Front Panel (JFP) | 1x Chassis Intrusion (JCI) | 1x Front Audio (JAUD) | 1x Com Port (JCOM) | 1x Tuning Controller connector(JDASH) | 2x Addressable V2 RGB LED connector (JARGB_V2) | 1x RGB LED connector(JRGB) | 1x TPM pin header(Support TPM 2.0) | 4x USB 2.0 ports | 4x USB 5Gbps Type A ports | 1x USB 10Gbps Type C ports
Warranty Information
Warranty 3 Years
