MSI PRO H610M-S DDR4 MOTHERBOARD

MSI PRO H610M-S DDR4 MOTHERBOARD
MSI PRO H610M-S DDR4 MOTHERBOARD
MSI PRO H610M-S DDR4 MOTHERBOARD
MSI PRO H610M-S DDR4 MOTHERBOARD
MSI PRO H610M-S DDR4 MOTHERBOARD
MSI PRO H610M-S DDR4 MOTHERBOARD
MSI PRO H610M-S DDR4 MOTHERBOARD
  • Stock: In Stock
  • Brand: MSI
  • Model: PRO H610M-S DDR4
  • SKU: PRO H610M-S DDR4
৳9,700
EMI starts at ৳3,333/month. View all 27 banks EMI plans >
Key Features:
  • Supports 12th Gen Intel Core, Pentium Gold and Celeron processors
  • LGA 1700 socket
  • Supports DDR4 Memory, up to 4600+(OC) MHz
  • PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
  • 2.5G LAN: Upgraded network solution for professional and multimedia use.
Product Details

MSI PRO H610M-S DDR4 MOTHERBOARD

The MSI PRO H610M-S DDR4 Motherboard is a reliable and feature-packed motherboard designed for professional use. With its Intel H610 chipset and mATX form factor, it offers a compact yet powerful solution for building desktop systems. The motherboard supports 12th Gen Intel Core processors, Pentium Gold, and Celeron processors, making it suitable for a wide range of computing needs.

In terms of memory, the MSI PRO H610M-S  supports DDR4 RAM with dual-channel mode and a maximum capacity of 64GB. It has two memory slots and supports memory speeds of 2133/2666/2933/3200 MHz. The motherboard also features four SATA 6Gb/s ports and one M.2 slot, allowing for flexible storage options and high-speed data transfers.

When it comes to connectivity, the MSI PRO H610M-S offers various ports and slots. It includes four USB 3.2 Gen 1 ports, two USB 2.0 ports, and audio ports on the rear panel. Additionally, it has internal connectors for USB and fan connections. The motherboard also supports multi-display capability with one HDMI port and one VGA port.

The MSI PRO H610M-S DDR4 Motherboard prioritizes stability and performance, thanks to its high-quality components and advanced features. It comes with a 7.1-channel high-definition audio system powered by the Realtek ALC892/ALC897 codec, delivering immersive sound for multimedia applications. The motherboard also includes a TPM module connector for enhanced security.

Overall, the MSI PRO H610M-S DDR4 Motherboard offers a solid foundation for a reliable and efficient desktop system. Its compact form factor, support for the latest Intel processors, and versatile connectivity options make it a suitable choice for professionals and enthusiasts alike.

MSI PRO H610M-S DDR4 Motherboard Features:

Here are some important features of MSI PRO H610M-S DDR4 Motherboard Features-

  • Intel H610 Chipset
  • Supports 12th Gen Intel Core Processors, Pentium Gold and Celeron Processors
  • Dual-channel DDR4 memory support
  • Realtek ALC892/ ALC897 Codec for 7.1-Channel High Definition Audio
  • Four SATA 6Gb/s ports and one M.2 slot (Key M, from chipset)
  • PCI Express 4.0 x16 slot
  • One PCIe x1 slot and one M.2 slot with E-key for PCIe WiFi module only (M2_ WIFI1)
  • 1x Intel I219V 1Gbps LAN controller
  • Multiple USB 3.2 and USB 2.0 ports
  • 03-year warranty

Here are some additional features of MSI PRO H610M-S DDR4 Motherboard-

  • Supports non-ECC, un-buffered memory
  • Supports Intel Smart Response Technology for Intel Core processors
  • Supports up to 64GB of DDR4 memory
  • Supports up to PCIe 3.0 x4 and SATA 6Gb/s
  • Supports 2242/ 2260/ 2280 storage devices
  • HDMI and VGA ports for display output
  • 24-pin ATX main power connector and 8-pin ATX 12V power connector
  • Front panel audio connector and chassis intrusion connector
  • Expansion slots: PCI Express x1 slot
  • 4-pin CPU fan connector and system fan connector

MSI PRO H610M-S DDR4 Motherboard Review:

The MSI PRO H610M-S DDR4 Motherboard delivers impressive performance, efficiency, and value, making it a compelling choice for users seeking a reliable and feature-rich motherboard. Designed with the Intel H610 chipset and a compact mATX form factor, it strikes a balance between power and space efficiency.

In terms of performance, the motherboard supports the latest 12th Gen Intel Core processors, Pentium Gold, and Celeron processors, providing ample processing power for various computing needs. The dual-channel DDR4 memory support with a maximum capacity of 64GB ensures smooth multitasking and efficient data handling. It also supports a wide range of memory speeds, from 2133MHz to 3200MHz, for enhanced system responsiveness.

The efficiency of the MSI PRO H610M-S motherboard extends beyond its performance capabilities. With support for Intel Smart Response Technology, it intelligently enhances system responsiveness by utilizing solid-state drives (SSDs) to cache frequently accessed data, resulting in faster boot times and application loading. The motherboard's efficient power delivery system, comprising a 24-pin ATX main power connector and an 8-pin ATX 12V power connector, ensures stable and reliable performance even during demanding tasks.

When it comes to value, the MSI PRO H610M-S offers an impressive array of features at an affordable price point. It provides four SATA 6Gb/s ports and one M.2 slot for flexible storage options, allowing for high-speed data transfers and support for various storage devices. The inclusion of USB 3.2 Gen 1 and USB 2.0 ports provides convenient connectivity options for peripherals. Additionally, the motherboard supports multi-display capability with HDMI and VGA ports, catering to users who require multiple monitors for their work or entertainment setups.

In conclusion, the MSI PRO H610M-S DDR4 Motherboard delivers exceptional performance, efficiency, and value. With its support for the latest processors, versatile storage options, and comprehensive connectivity features, it offers a solid foundation for building reliable and efficient desktop systems. Whether you're a professional user or an enthusiast, this motherboard is a worthy investment for its combination of performance, efficiency, and affordability.

Specification
GPU Specification
Multi Display Capability12
Motherboard Specification
ChipsetIntel H610 Chipset
Form FactormATX Form Factor
9.29 x 7.95 in. (23.6 cm x 20.2 cm)
AudioRealtek ALC892/ ALC897 Codec
7.1-Channel High Definition Audio
Socket1700
Memory Specification
Memory TypeDDR4
Max Number of ChannelsDual
Memory Capacity64
Memory Slots2
Supports
Supported CPUSupports 12th Gen Intel Core Processors, Pentium Gold and Celeron Processors
Processor socket LGA1700
Supported MemorySupports 1R 2133/ 2666/ 2933/ 3200 MHz (by JEDEC & POR)
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supported Storage4x SATA 6Gb/s ports
1x M.2 slot (Key M, from chipset)
Supports up to PCIe 3.0 x4
Supports up to SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
Supports Intel Smart Response Technology for Intel Core processors
Connectors
LAN1x Intel I219V 1Gbps LAN controller
USBIntel H610 Chipset:
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB
connector) 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0
connector)
HDMI1
TPM (Trusted Platform Module )1x TPM module connector
VGA1
Ports & Slots
SlotsM.2 SLOT 1
PortsUSB 3.2 Ports (Front) 2(Gen 1, Type A)
USB 3.2 Ports (Rear) 2(Gen 1, Type A)
USB 2.0 Ports (Front) 2
USB 2.0 Ports (Rear) 4
Audio Ports (REAR) Realtek ALC892/ ALC897 Codec
Internal I/O PortsPOWER CONNECTORS:
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
FAN CONNECTORS:
1x 4-pin CPU fan connector
1x 4-pin system fan connector
SYSTEM CONNECTORS:
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
Expansion SlotsPCI
1x PCIe x16 slot (From CPU)
Supports up to PCIe 4.0 x16
1x PCIe x1 slot
Supports PCIe 3.0 x1
1x M.2 slot with E-key for PCIe WiFi module only (M2_ WIFI1)
Physical Specification
Dimensions (W x D x H)304*243mm
Warranty Information
Warranty03 year
