- Stock: In Stock
- Brand: Thermaltake
- Model: PS-TPT-0750FNFAGK-W
- SKU: PS-TPT-0750FNFAGK-W
Key Features:
- 80 Plus Gold
- PCIe 5.1 (12V-2x6, 300W) & ATX 3.1
- 120mm Hydraulic Bearing Fan
- 4 x PCIe Connectors (6+2 pin)
- Protection: OVP/UVP/OCP/OPP/OTP/SCP
Thermaltake ToughPower GT 750W 80 Plus Gold Power Supply
This 80 Plus Gold-certified ToughPower GT Power Supply from Thermaltake provides up to 750W of power to the components in your PC build. The 120mm cooling fan keeps your components cool and won't spin until the power demand exceeds 30% load. The ToughPower GF A3 power supply comes with four PCIe connectors for graphics cards and other devices, a PCIe Gen 5.1 12V-2x6 connector for the latest generation NVIDIA graphics cards, and eight SATA connectors for storage devices and disc drives. The ATX form factor fits most cases, and the flat cables make cable management a breeze.
Power Up the Next Generation Hardware
To fully support next-gen hardware, Toughpower GT Gold Series is designed to meet ATX 3.1 standards, including a PCIe Gen 5.1 12VHPWR connector. The GF A3 Gold series delivers 80 PLUS Gold efficiency, and it also offers stability, durability, and reliability.
Fully Compatible with Intel ATX 3.1 Standards
Toughpower GT Gold series is fully compatible with Intel ATX 3.1 Specifications, which supports up to 200% power excursion, reaches 60% low load efficiency, and complies with required power supply timing standards.
PCIe Gen 5.1 Ready
Toughpower GT Gold series comes with a 12V-2x6 connector to offer powerful and stable performance, allowing the PSU to run latest-generation GPUs natively.
The wattage marked on the 12VHPWR’s connector is the recommended wattage. (Ref. Intel design guideline)
The native 16 PIN (12V-2x6) PCIe connector of the GT 750W can deliver up to 300W for PCIe 5.1 graphics cards.
Made to Comply with the Latest Graphics Cards
As the power consumption of graphics cards increases, so does their power demand. The GT series is designed to support NVIDIA & AMD graphics cards and is ready to supply the graphics cards according to their different connections.
| Power Supply Specification | |
| WATT | 750W |
| Fan Size | 120mm Hydraulic Bearing Fan |
| Efficiency | Meet 80 PLUS® Gold at 115Vac input. |
| Certification | 80 Plus Gold |
| Continuous Power | 750W |
| HOLD UP TIME | > 17msec at 80% load |
| MTBF | 100,000 hrs minimum |
| POWER GOOD SIGNAL | 100-250 msec |
| Safety Approval | CE/UKCA/ICES/TUV/LVD/RCM/CB/FCC/cTUVus/BSMI/CCC/BIS/S-MARK |
| OPERATING HUMIDITY | 5% to 85%, non-condensing |
| OPERATING TEMPERATURE | 0°C to + 45°C |
| PCI-E 6+2PIN | PCIe 5.1 (12V-2x6, 300W) x 1<br> PCIe 6+2 pin x 4 |
| PFC (POWER FACTOR CORRECTION) | Active PFC |
| STORAGE HUMIDITY | 5% to 95%, non-condensing |
| STORAGE TEMPERATURE | -40°C to + 70°C |
| Voltage | 100-240V~ |
| Frequency Range | 50Hz - 60Hz |
| Current | 750W |
| Modular Type | Full Modular |
| Total Power | 750W |
| DC Output | 750W |
