UNV ESS-HB5-R02 High-Voltage Rack-Mount Battery System
Scalable, High-Performance Energy Storage for Modern Power Needs.
Upgrade your energy independence with the UNV ESS-HB5-R02, a high-voltage, rack-mounted Lithium Iron Phosphate ($\text{LiFePO}_4$) energy storage solution. Engineered for efficiency, safety, and flexible expansion, this 3U standard-height modular battery pack is designed to meet demanding commercial and residential power requirements.
Key Highlights
- Flexible & Scalable Storage: Build a custom setup with 4 to 16 battery packs per cluster. Expand up to 2 parallel clusters to achieve a total energy storage capacity of 120 kWh.
- High-Rate Performance: Supports up to 1C continuous charging and discharging (100A max), delivering reliable power when you need it most.
- Ultra-Safe {LiFePO} Chemistry: Built with safe Lithium Iron Phosphate technology and featuring dual electrical fuse protection on both the battery unit and the high-voltage control box.
- Quick & Easy Installation: Comes with integrated quick-connect plugs and floor-mounting capability to significantly speed up deployment.
- Smart Diagnostics: Features a fault code display and abundant fault-diagnosis protections for fast, effortless maintenance.
- Built to Last: Long cycle life of more than 3,500 cycles at 100% Depth of Discharge (DOD) under optimal operating conditions.
